Cảm biến nhiệt độ Dwyer TE Series

Liên hệ có giá tốt nhất

Tính năng sản phẩm

The Series TE Duct and Immersion Building Automation Temperature Sensors
can be used to monitor air or water temperature throughout a building management
system or an air handler unit. Duct or immersion options available with or without an
enclosure.
BENEFITS/FEATURES
• Easy to mount external tab housing and flange options for duct applications
• 1/4 turn housing cover with chain to prevent dropping
• Multiple conduit knockouts for easy installation positioning
• 8´ plenum rated cable option
• Terminal connector eliminates need for wire nuts
APPLICATIONS
• Building automation
• VAV temperature sensing
• Chiller or boiler loops
• AHU monitorin

TE.pdf DS_TE.pdf

LIên hệ đặt hàng

0968425418

Thông tin kỹ thuật

Accuracy: Thermistor temperature sensor: ±0.22°C @ 25°C (±0.4°F @ 77°F); RTD
temperature sensor: DIN class A: ±0.15°C @ 0°C (±0.28°F @ 32°F).
Temperature Limits: Operating: -40 to 302°F (-40 to 150°C).
Sensor Curves: See page reference u below.
Cable Rating: Plenum option includes UL listed plenum cable.
Housing Material: Meets UL, 94 V-0 polycarbonate plastic.
Housing Rating: NEMA 4X (IP66) (DFW, IBW only).
Weight: 5.3 oz (150.3 g).
Compliance: Meets the technical requirements of EU Directive 2011/65/EU (RoHS
II).
